Electromagnetic Flow Meter

Superior fluid measurement for an array of applications

H2flow Controls has over 20 years of specialist competence integrating flow management solutions to a variety of different industries and applications. Built to exacting standards, the FaraMag™ FM750 represents precision in it’s finest form.

FM750 is available for a wide range of 0.5” – 120” (DN15 – DN3000) pipe diameters, and because of their incredible accuracy and reliability, FM750 mag meters are also ideal for many critical applications. Across the entire model range, FM750 boasts an impressive ±0.5% average accuracy.

Features include:

  • No moving parts to impede the flow
  • Compact and remote versions available
  • A wide range of material options for sensor body, liner and electrodes
  • Intuitive controls and available remote control for simplified programming
  • Displays instantaneous flow, flow units, or cumulative flow
faramag electromagnetic flowmeter


Pipe Diameters

DN15, DN20, DN25, DN40, DN50, DN65, DN80, DN100, DN150, DN200, DN250, DN300, DN350, DN400, DN450, DN500, DN600, DN700, DN800, DN900, DN1000, DN1200, DN1400, DN1600, DN1800, DN2000, DN2200, DN2400, DN2600, DN2800, DN3000

Average Accuracy

±0,25% of the Relative Range
Pressure rating87 – 580 psi / 6 – 40 Bar
Sensor Material

Carbon Steel (standard), 304 Stainless Steel (optional), 316 Stainless Steel (optional)

Inner Lining

Hard Rubber (standard), PTFE (optional), refer to technical specifications document for additional options

Protection ClassIP65 (standard), IP67 e IP68 (optional)
Power Supply120-230VAC, 12-24VDC, 3.6V
Con una precisión inigualable, una mayor flexibilidad de instalación y más modelos con certificación independiente que cualquier otra marca de caudalímetros, es fácil ver por qué AcuFlow™ es un caudalímetro en el que puede confiar.

Las características incluyen:

  • Disponible en tuberías con diámetros desde DN40 hasta DN200.

  • Presión máxima de 8.62 Bar / 125 psi.

  • Mejora digital disponible.

  • Instalación fácil e intuitiva.

  • >98.1% precisión media.

Para una variación de este producto diseñado específicamente para piscinas y spas, por favor, considere el caudalímetro FlowVis For a variation of this product developed specifically for swimming pools and spas, please consider the FlowVis® flow meter.

The remote-type FM750 is the ideal solution for meters positioned in difficult-to-access installations. The standard cable length allows the product’s large, user-friendly backlit LCD display to be placed up to 10M away from the sensor body.

Nominal Diameters: DN15 – DN3000

Accuracy: ±0.25% of Relative Range.

Flange Types: ANSI, DIN

Both compact- and remote-type standard FM750 Carbon Steel sensor bodies can be upgraded to either 304 or 316 Stainless Steel. This is ideal for many food & beverage and pharmaceutical applications. Sanitary-type are available with ANSI, DIN and tri-clamp flanges.

Nominal Diameter: DN15 – DN3000

Accuracy: ±0.25% of relative range.

Flange Types: ANSI, DIN, Tri-clamp

electromagnetic flow meter

The FM750 is available in a variety of configurations. The compact-type allows for local access to readings on it’s user-friendly backlit LCD display. A variety of their options, electrode materials and communication options are available in a wide range of sizes.

Nominal Diameters: DN15 – DN3000

Accuracy: ±0.25% of relative range.

Flange Types: ANSI, DIN

electromagnetic flow meter

The FM750 Insertion-type mag meter utilizes the NIKURADSE principle, allowing for simplified installation and reduced costs. The meter is ideal for cast iron and cement pipe, and offers many of the same features as other FM750 models. Units are available for DN200 – DN3000 pipe.

Nominal Diameters: DN200 – DN3000

Accuracy: ±1.5% of displayed value.

Flow Meter Body: Acero inoxidable
